AUR6000 UHF Long Range RFID Readers

A multi-protocol, multi-tag, integrated reader. Suitable for both indoor and outdoor use.

Enquiry
aur6000

The AUR6000 family of long range readers is a multi-tag, integrated reader. Elegantly designed in an IP66 beige housing, the reader is suitable for both indoor and outdoor use.

The reader operates with passive cards/tags and is used in a variety of applications, including car park management. The passive technology makes this solution ideal, eliminating the need for regular card maintenance or replacement.

Key Features

  • Very long range with up to 8 meters
  • Hands-free operation
  • Outdoor weatherproof housing with adjustable mounting bracket
  • Passive technology—maintenance– free cards/tags without battery
  • Ideal for vehicle identification
Specifications* AUR6102
Description UHF Long Range RFID Reader
Read Range 8000mm with ISO Card (or up to 2m when transponder is placed inside vehicle or subject to other inferences)
Dimension (H x W x D) 600 x 480 x 110mm
Weight 5000g
Buzzer Multi-tone
Communication Interface Wiegand 26/34 / RS232 / RS485
Input Voltage 9-15VDC
Current Consumption 4000A at 12VDC Max
Color Beige
Mounting Surface mount
Operating Temperature -20 °C to 60 °C
Environmental Weatherproof
Frequency Range US (902-928MHz), China (920-925MHz), EU (865-867MHz)
Antenna Built-in with 12dbi Gain
Read Rate Multi-tag (200pcs/sec), Single-tag (2000pcs/min)
Read Mode Periodic Scan or External Trigger
Card Format ISO18000-6B / ISO18000-6C (EPC Gen 2)
RF Power Output 0 – 31 dBm

*Specifications are subject to change without prior notice

Datasheet: https://www.asis-technologies.com/datasheets/readers-datasheets/

Model No. Description
AUR6102 UHF Long Range Reader (up to 8m)

Additional information

Weight 5 kg
Dimensions 62 × 48 × 11 cm
