Roll Call Report (RCR)

Roll Call Report is an add-on module of IBSSweb that allows user to generate reports based on the event transaction database, with configurable options including zone, entry/exit devices, presence/absence, and time/date.



Enquiry
Module_RCR
Module_RCR
Roll Call Report UI with Monitor
Roll Call 1
Roll Call 2
Roll Call 3

Roll Call Report from IBSSweb allows user to generate reports based on the event transaction database, with configurable options including zone, entry/exit devices, presence/absence, and time/date.
The configuration parameters can be saved in a profile record for quick and easy access. This software module is suited to emergency roll call, incident investigation, occupation analysis, attendance reports, etc.

Key Features

  • Zones with one or more department codes can be configured
  • Configurable entry/exit readers within each zone
  • Reports can be generated for present or absent users
  • Select whether to consider event messages as Access Granted only or Access Granted & Denied
  • Display of last entry/exit point with date/time information
  • Full record filter parameter list and report summary as report headers
  • All configurable parameters are stored in a profile record for easy retrieval and operation
Specifications IBSSweb-RCR
Description IBSSweb Roll Call Report
IBSSweb Versions IBSSweb Professional Edition or above (Prerequisite)
Supported Operating System Windows 10 (64bit) / Windows Server 2016 or above
Zone Select 1 or more Department Codes
Entry/Exit Device Select 1 or more Readers as Entry Device or Exit Device
Report Type – Present i. Last event related to Zone Entry Reader
ii. Last Event Datetime between Start Date and End Date
iii. Last event cardholder department included zone department
iv. Last Event Type included Event type (Access Granted/Access Granted or Access Denied)
Report Type – Absent i. Last event related to Zone Exit Reader
ii. Last Event Datetime between Start Date and End Date
iii. Last event cardholder department included zone department
iv. Last Event Type included Event type (Access Granted/Access Granted or Access Denied)
v. Cardholder who under department of the zone but no event record found between Start Date and End Date. (Status = Absent)
Overstay Limit 0 to 24 Hours
Sorting Mode Sort Options:
a) Zone, Department, Cardholder Name (Default)
b) Zone, Cardholder Name
Export Format PDF, XLS, XLSX, PPT, RTF, TIFF, MHTML, DOCX, XPS


*Specifications are subject to change without prior notice

Datasheet: https://www.asis-technologies.com/datasheets/software-datasheets/

Model No. Description
IBSSweb-RCR IBSSweb Roll Call Report
